一、防火卷簾門不動作：

1、 Fireproof rolling shutter door does not operate:

應檢查電源，看防火卷簾門的電源空開是否有電，如果沒電，就應線檢查電源部分。如果有電，此時卷簾控制箱的電源指示燈應當是綠色常亮。如果指示燈不亮此時我們應檢查控制箱內的變壓器(變壓器的電阻270歐姆)是否燒壞。如果電源指示燈是綠色閃爍，表明電源部分可能缺相，如果電源不缺項有可能是控制箱的備用電源板燒壞;也有可能住電源板和備用電源板都燒壞。

The power supply should be checked to see if the power switch of the fireproof rolling shutter door has power. If there is no power, the power supply should be checked online. If there is electricity, the power indicator light of the roller shutter control box should be green and always on. If the indicator light is not on, we should check if the transformer (with a resistance of 270 ohms) inside the control box is burnt out. If the power indicator light is flashing green, it indicates that the power supply may be out of phase. If the power supply is not out of phase, it is possible that the backup power board of the control box is burnt out; It is also possible that both the residential power board and the backup power board are burnt out.

二、電源空開推不上：

2、 Power switch cannot be pushed up:

送閘時，空開推不上應檢查備用板是否有問題，備用板的輸出線的電阻約為300歐姆。如果開路時或短路應該檢查電機的點剎車是否燒壞，或檢查備用板是否燒壞。

When the air switch cannot be pushed up, check if there is a problem with the backup board. The resistance of the output line of the backup board is about 300 ohms. If there is an open circuit or a short circuit, check if the motor's point brake is burnt out, or check if the backup board is burnt out.

三、操作按鈕使用不靈：

3、 The operation button is not working properly:

應當先按下停止鍵，再按下復位鍵，然后按上行下行鍵。

You should first press the stop button, then press the reset button, and then press the up and down buttons.

四、電源控制箱或按鈕面板的指示燈全亮：

4、 The indicator lights on the power control box or button panel are all on:

這時應先檢查按鈕線是否有短路現象或某一個按鈕被壓死的可能，如果以上現象不存在，有可能是電源主板上的芯片壞掉，這時應更換芯片。注意要反著裝，(即開口對著開口)。

At this point, it is necessary to first check whether there is a short circuit in the button wire or the possibility of one button being pressed. If the above phenomena do not exist, it is possible that the chip on the power supply motherboard is damaged, and the chip should be replaced. Be sure to dress in the opposite direction (i.e. facing the opening).

五：按鈕操作只有上行或下行：

5： The button operation can only be up or down:

這時應先檢查限位線是否有掉線現象，若果沒有，有可能是主電源板壞了。

At this point, it is necessary to first check if there is any disconnection in the limit wire. If not, it is possible that the main power board is damaged.

六、操作按鈕不好用或按什么按鈕都是下行：

6、 The operation button is not easy to use or any button pressed will go down:

應先檢查主電板與備電板的連接排線時是否松動。

First, check if the connection cables between the main and backup electrical boards are loose.

七、增加鎖控：

7、 Add lock control:

只需在排線的第5和12的空上串接一個約1K的電阻。

Just connect a resistor of approximately 1K in series on the 5th and 12th spaces of the ribbon cable.

八、判斷電機的好壞：

8、 Judging the quality of the motor:

電機的三相電阻達47-70歐姆且三相平衡。三相不平衡可能是電機壞了。

The three-phase resistance of the motor reaches 47-70 ohms and the three phases are balanced. Three phase imbalance may be due to motor failure.

九、防火卷簾門報警時，應當先讓防火卷簾門自動下降到底，途中不要按任何按鈕，然后再上行。

9、 When the fire shutter door alarms, the fire shutter door should be automatically lowered to the bottom first, and no buttons should be pressed during the process before going up.

十、防火卷簾門的安裝調試：

10、 Installation and commissioning of fireproof rolling shutter doors:

在安裝調試之前應先檢查控制器、按鈕盒、卷門機、行程開關、電剎車的連接線是否正常，確認后在進行調試。

Before installation and debugging, it is necessary to check whether the connection wires of the controller, button box, rolling door machine, travel switch, and electric brake are normal, and then proceed with debugging after confirmation.
